120mm Case Fan

Kaze Flex II 120 Slim

Scythe newly designed Kaze Flex II Slim Quiet PC case fan focuses on an optimized fan frame. With a slimmer frame body, Kaze Flex II is now 1mm slimmer than its predecessor and generates more air flow to cool your high TDP PC down.

KFS1215FD12-P
KFS1215FD15-P
KFS1215FD18-P

Anti Vibration Rubber

Equipped with Anti-Vibration rubber allows Kaze Flex II slim fan to contribute nearly silent operation by absorbing possible vibration transmission.

High Precision FDB

With proprietary Fluid Dynamic Bearing, Kaze Flex 120 Slim fan provides quiet cooling as well as long lifespan up to 120,000 hours. The bearing and pressure shaft are made of high-quality compressed metal, it is to guarantee minimum tolerance and excellent stability.

SPECIFICATIONS

Dimension : 120 x 120 x 15 mm

Bearing : High Precision FDB

MTTF : 120,000 hrs

Current : 12V

Weight : 106 g ± 10%

Accessory : Metal Screw X 4、Screw Pin Rivet X 4、200mm 4-Pin Extension Cable X 1

KazeFlex 120 II Silm pwm(1215)-PPN220328_S_o-01.png

Speed

(RPM)

300±200~1200±10%

300±200~1500±10%

300±200~1800±10%

Model Number

KFS1215FD12-P

KFS1215FD15-P

KFS1215FD18-P

Air Flow

(CFM)

8.16 ~ 32.00

8.16 ~ 39.44

8.16 ~ 48.00

Statics

(mmH2O / Pa)

0.045 ~ 0.640 / 0.44 ~ 6.28

0.045 ~ 0.960 / 0.44 ~ 9.41

0.045 ~ 1.360 / 0.44 ~ 13.34

Noise

(dBA)

2.58 ~ 21.30

2.58 ~ 23.80

2.58 ~ 27.80

Current

(A)

0.06

0.08

0.18
